Fruit and Vegetable Pulper
video
Fruit and Vegetable Pulper

Fruit and Vegetable Pulper

​The fruit and vegetable pulper is suitable for the beating of tomato, celery, strawberry, blueberry, mango and other fruits and vegetables. The following introduces a special kind of pulper: Passion fruit pulper. It is suitable for halving/cutting and digging out the pulp of passion fruit to obtain pure passion fruit with seeds.

Features

Industrial Fruit and Vegetable Pulper & Specialized Processing Equipment

Kassel Machinery supplies advanced fruit and vegetable pulpers engineered for high-capacity juicing, seed separation, and puree production. Beyond standard multi-purpose pulpers for tomatoes, mangoes, berries, and root vegetables, we specialize in heavy-duty passion fruit cutting, halving, and seed-extracting pulpers designed for commercial beverage and fruit processing plants worldwide.

Engineering Superiority & Specialized Machinery

  • Specialized Passion Fruit Extraction: Dual-roller cutting, counter-pressure pressing, and scraper-digging mechanisms cleanly isolate whole juice and seed sacs from tough rinds.
  • Variable-Speed Noise Reduction Motor: Low-decibel operational design with high-torque gearboxes ensures smooth, vibration-free continuous performance.
  • Multi-Layer Grinding & Uniform Texture: Sharp high-speed steel blades crush materials layer by layer without dead angles, yielding smooth, fiber-refined purees.
  • Sanitary Food-Grade Construction: Built strictly from heavy-duty SUS304 and SUS316L stainless steel, meeting international FDA and GMP standards.

Pulper Model Configurations & Technical Parameters

Equipment Series Standard Fruit & Vegetable Beater Passion Fruit Cutting & Extracting Line
Processing Capacity 1.0 Ton/h - 5.0 Tons/h 500 kg/h - 2.5 Tons/h (Specialized Cut & Scoop)
Blade / Screen Material SUS304 Conical Screens & Beater Paddles High-Speed Tool Steel Blades & SUS316L Scrapers
Motor Drive Variable Frequency Speed Control Motor Low-Noise Reduction Geared Motor Drive
Sanitary Compliance CE Certified, FDA Food-Grade Compliant CE Certified, GMP Sanitary Standards
Target Applications Tomatoes, strawberries, mangoes, celery, berries Passion fruit, citrus, seeded stone fruits

Integrating Fruit Pulping with Advanced Vacuum Lyophilization

High-purity, uniform fruit and vegetable purees serve as the perfect base material for premium freeze-dried fruit powders, instant smoothie blocks, and nutritional supplements. As global vacuum freeze dryer manufacturers, Kassel Machinery provides turnkey processing lines linking raw fruit pulping and sorting directly to industrial vacuum freeze drying systems.

Pairing our specialized fruit pulpers with state-of-the-art lyophilizers guarantees complete preservation of natural vitamins, active enzymes, and authentic fruit aromas without chemical preservatives.

Looking for Custom Fruit & Vegetable Pulper Solutions?

Speak with our engineering team for customized pulper blade configurations, capacity sizing, and factory-direct equipment quotations.

Request Technical Proposal & Quote

The fruit and vegetable pulper is suitable for the beating of tomato, celery, strawberry, blueberry, mango and other fruits and vegetables. The following introduces a special kind of pulper: Passion fruit pulper. It is suitable for halving/cutting and digging out the pulp of passion fruit to obtain pure passion fruit with seeds.



1. Passion fruit cut and half pulper

Structural features and working principle: The machine is mainly composed of three counter-pressing rollers, two knife rollers, one feeding roller, a feeding hopper, a pulping hopper, a leather hopper, a frame, and a transmission. When working, turn on the power supply and pour the material into the feeding hopper. The material first passes through the middle of the two knife rollers, and is pressed into the middle of the two knife rollers by the feeding roller for cutting. Passion fruit pulp with seeds is discharged from the pulping hopper. The skin is further pressed by three pressing rollers and then discharged from the skin hopper, so as to achieve the purpose of pulp extraction.



2. Passion fruit peeler and pulper

Structural features and working principle: The machine is mainly composed of a frame, a cutting knife, a pulp scraper, a peeling bucket, a pulp outlet, and a transmission part. When working, the fruit is manually placed at the entrance of the cutting knife. Then place the slitted passion fruit on the digging scraper for digging, so as to obtain the passion fruit puree with seeds; the machine is made of stainless steel except for the transmission parts, and the blade is made of high-speed steel.



The fruit and vegetable pulper adopts a variable speed noise reduction motor, which effectively reduces the decibel. Sharp cutter head, crushing and grinding layer by layer without dead ends, making the beating more delicate and uniform. We provide various types of fruit and vegetable pulper, welcome to leave a message for consultation.
