High Speed Fruit Pulper Machine

High Speed Fruit Pulper Machine

The High Speed fruit pulper machine first cuts the vegetables and fruits into segments by the rotary cutter at the feeding port and then chops them into small segments by the high-speed rotating hammer cutter to make pulp at one time. It is an ideal machine for making jams, fruit juices, and vegetable juices, and is suitable for pulping a variety of fresh fruits and vegetables. Berry products, such as orange flesh, grapes, kiwi, mulberry, bayberry, peach, etc. can be made into sauce, and green vegetables (cut), tomatoes, peppers, celery, etc. can be made into vegetable juice, which is used for food processing enterprises. important equipment. Mainly suitable for beet, rape and various root crops (sweet potato, potato, radish, carrot, pumpkin) beating, the pulp produced has a long storage time, small loss of nutrients, and good taste.

High Speed fruit pulper machine has a variety of uses and is easy to operate. It is widely used in restaurants, canteens, bakeries, hotels, food processing factories, and other places. It is an ideal piece of equipment for producing high-quality food and cakes. The stainless steel fruit and vegetable beater are mainly used for beating, peeling, pitting, etc. of raw materials such as berries and tomatoes, so as to separate the pulp, juice, etc. from other parts, which is convenient for the concentration of juice and the completion of other subsequent processes.

1. Stone fruits

The motor is driven by a V-belt to make the rotor parts rotate at high speed. The fruit is sent from the feeding port to the machine, and the feeding paddle conveys the material to the beating rod. Under the action of the beating rod, the material is smashed. Due to the action of centrifugal force, the juice and meat in the material (which have become pulpy) enter the next process through the sieve holes on the screen, and the core is discharged from the slag outlet through the slag discharge blade, thereby realizing the automatic separation of pulp and slag.

2. Berries

The motor is driven by a V-belt to make the scraper installed on the spline shaft rotate at a high speed. When the crushed fruit enters the machine through the feeding port, the pulp baffle plate evenly discharges the material between the scraper and the screen. Due to the rotating action of the scraper and the existence of the lead angle, the material moves along the cylinder to the outlet end, and the moving trajectory is spiral, and the material is affected by centrifugal force during the movement between the scraper and the screen. Grind, the juice and meat (in slurry form) pass through the sieve hole and enter the next process (the double beater is linked to repeat the above process), and the skin and seeds are discharged from the slag hopper, so as to achieve the purpose of automatic separation. As long as the screens of different specifications are changed and the lead angle of the scraper is adjusted, different beating speeds can be changed, and the effect is good.
